qrframe

framework for making qr codes

Blatantly inspired by QRBTF and Anthony Fu's QR Toolkit.

Examples

I'm working on more examples.

Creative possibilities
Import external libs, fetch external files, etc
Styles copied from QRBTF
Boring options are available

Features

• Customize data:

  • encoding mode, version, error tolerance, mask pattern
  • powered by fuqr, my own Rust library imported as WASM. (i use windows, btw)

• Customize appearance:

  • Choose any preset, customize or even create a new one from scratch via code editor.
  • Define arbitrary UI parameters in code
  • Supports SVG and PNG
  • All code runs directly in browser in a web worker with no restrictions.
    • There is no sandbox, whitelist, blacklist, or anything besides a 5s timeout to stop infinite loops.
    • Generated SVGs are not sanitized. This is an impossible task and attempting it breaks perfectly fine SVGs, makes debugging harder, and adds latency to previewing changes.
    • These should be non-issues, but even if you copy-and-paste and run malware there's no secrets to leak.

Use existing presets

Customizable parameters defined in code

Creating a preset

A preset must export paramsSchema and either renderSVG or renderCanvas

paramsSchema

This schema defines the UI components whose values are passed into renderSVG or renderCanvas via the params object.

All properties besides type are optional, except

• type select must have a nonempty options array
• type array must have a valid props value.

In this example, default is set explicitly to the implicit default value.

export const paramsSchema = {
  Example1: {
    type: "number"
    min: 0,
    max: 10,
    step: 0.1,
    default: 0,
  },
  Example2: {
    type: "boolean",
    default: false,
  },
  Example3: {
    type: "color",
    default: "#000000"
  },
  Example4: {
    type: "select",
    options: ["I'm feeling", 22]
    default: "I'm feeling",
  },
  Example5: {
    type: "file",
    accept: ".jpeg, .jpg, .png"
    default: null,
  },
  Example6: {
    type: "array",
    props: {
      type: "number" // any type except "array"
      // corresponding props
    },
    resizable: true,
    defaultLength: 5, // overridden by default
    default: [], // overrides defaultLength
  }
}

renderSVG and renderCanvas

type renderSVG = (qr: Qr, params: Params) => string;

type renderCanvas = (qr: Qr, params: Params, canvas: OffscreenCanvas) => void;

params is an object with all the keys of paramsSchema paired with the value from their respective input component.

qr contains the final QR code in matrix. This represents a square where one side is version * 4 + 17 wide, and modules (aka pixels) are stored from the left to right, top to bottom.

type Qr = {
  matrix: Module[] // see below
  version: number; // 1- 40
  mask: number; // 0 - 8,
  ecl: number; // 0 - 3, Low, Medium, Quartile, High
  mode: number; // 0 - 2, Numeric, Alphanumeric, Byte
};

enum Module {
  DataOFF = 0,
  DataON = 1,
  FinderOFF = 2,
  FinderON = 3,
  AlignmentOFF = 4,
  AlignmentON = 5,
  TimingOFF = 6,
  TimingON = 7,
  FormatOFF = 8,
  FormatON = 9,
  VersionOFF = 10,
  VersionON = 11,
  SeparatorOFF = 12,
}
